| MATERIAL: | Paint | Mateial: | SS |
|---|
![]()
| Technical Parameter | |
| Items | Content |
| Packing speed | 15-80bags/min |
| Bag size | (W)70-200 * (L)50-300 & 400mm |
| Bag making mode | Pillow-type bag,Standing bag,Link-bag device, Punch device |
| Range of measuring | 150-1500ml |
| The maximum width of packing film | 420mm |
| Thickness of film | 0.04-0.1mm |
| Air consumption | 0.6Mpa 400L/min |
| Main powder/volttage | 2.5kW/220V 50-60Hz |
| Main Dimension | (L)1400*(W)970*(H)1700 mm |
| The weight of switchboard | 450Kg |
| Film material suggestion | POPP/CPP,POPP/PE,PET/VMPET/PE,PET/AL/PE,NY/PE,PET/PET and so on |
1.The scope of packaging
It’s suitable to use in packing the high accuracy and easy fragile material , such as : puffy food , crispy rice , Potato Chips , Snacks , candy , pistachio , sugar , apple slices , dumpling , chocolate , pet food , small wares etc .
![]()
![]()
![]()
![]()
![]()
